We use the Conventional Commits, here is a link that shows the commit standard we use : https://www.conventionalcommits.org/en/v1.0.0-beta.4/

Here are few basic examples of commit message with a description.
fix: correct minor typos in code

feat: allow provided config object to extend other configs

feat(lang): add polish language

ci: run linters on pull requests

You can install "Conventional Commits" extension on your editor to make it easier to understand

Pr's title convention

<type>[branchefrom > brancheto]: <description>

Use conventional commits for the title of PR. here is an example

 {feat(server}

## Commit's convention  merge

Use the default git message

## Tickets's convention

- title:
       ```<type>: <description>

example: fix: connection client

description:
for features: exact details on what you want to be done to complete this ticket.
for bugs: exact details on how to reproduce the bug (and maybe where you think the problem comes from)
labels: link tickets to every labels that can be related to them.
milestones: link tickets to every milestones that can be related to this ticket.

**/!\ don't forget to assign the ticket to the person who need to work on it.**

TCP/UDP Protocol Documentation

Introduction

This document provides an overview of the TCP and UDP protocol used in our project.

Protocol Overview

Purpose

The UDP protocol is designed for fast and lightweight communication.

Packet Structure

packets send by the server have a simple structure consisting of:

Header struct with:
{c++}

struct header {

int RFC; // RFC code

int id; // id of the concerned entity in the registry

};
structure body depending of the RFC number
int of the RFC code to finish the sended data

packets sends by the client are the header struct with the RFC code and the id of the client.

Connection

The connection part is in TCP
When a client is connecting to the server, the client need to send the magic number 81732 in the rfcCode variable of the header. Then the connection can be established

Error Codes

In case of errors, the protocol uses the following error codes:

401: Forbidden: This code is used when the server refuse the connection in the format:
{c++}

struct header {

code: 401;

entity: -1;

};

401

Client Codes

TCP

Connection: The client connect to the server and send the magic number (81732). Then the server respond with this:
{c++}

struct header {

code: 200;

entity: index of the player;

};

number of clients connected (including you)

200
201: Lauch game: this made the server change to udp and send to every clients:
{c++}

struct header {

code: 201;

entity: index of the player;

};

port to connect on udp

201
202: new player: sended by the server when new client is connected
{c++}

struct header {

code: 202;

entity: your index of player;

};

number of players

202
203: solo
204: multi

210 Commands

 {c++}
struct header {
    code: 21X;
    indexPlayer: 0;
};

217: CONNECTED: This code is used when the client connect to udp and confirm to server he is on udp
211: UP: This code is used when the client move up
212: DOWN: This code is used when the client move down
213: LEFT: This code is used when the client move left
214: RIGHT: This code is used when the client move right
215: SHOOT: This code is used when the client shoot
216: DROP: This code is used when the client drop the force pod

22X Win/Lose

 {c++}
struct header {
    code: 22X;
    entity: 0;
};
22X

221: WIN: this code is send to indicate win
222: LOSE: this code is send to indicate lose
223: RIGHT: this code is send to indicate that the team on the RIGHT won (PVP)
224: LEFT: this code is send to indicate that the team on the LEFT won (PVP)

23X Stage

 {c++}
struct header {
    code: 231;
    entity: stage level;
};
231

231: [Stage]: this code indicate the new stage

24X Mode

 {c++}
struct header {
    code: 24X;
    entity: 0;
};
24X

241: this code indicate the classic mode
242: this code indicate the infini mode
243: this code indicate the friendly fire mode
244: this code indicate the pvp mode

Server Codes

3XX: entity

30X: spawn mob

301: (Pata-Pata) [X, Y]
302: (Bink) [X, Y]
303: (Scant) [X, Y]
304: (Bug) [X, Y]
305: (Cancer) [X, Y]
306: (Blaster) [X, Y]
307: (Dobkeratops) [X, Y]

31X: spawn ally

311: (Player) [X, Y, Enum: Color]
312: (Ally) [X, Y, Enum: Color]

32X: spawn missile

321: (Classic) [X, Y, VelocityX, VelocityY, Enum: Team]
322: (Wave Beam) [X, Y, VelocityX, VelocityY, Enum: Team, Force]
323: (Bydo Shot) [X, Y, VelocityX, VelocityY, Enum: Team]

33X: existing entities

The server send 331 and 332 of the same entity just after to avoid a shift

331: positions of the entities (id of entity in the header and use for body PositionComponent) and velocity of the entities (id of entity in the header and use for body VelocityComponent)
If the entity don't have a PositionComponent, the server send a PositionComponent with -1 and -1 inside, same for VelocityComponent
{c++}

struct header {

code: 331;

entity: index of the entity;

};

struct PositionComponent "((-100, -100) if not defined)"

struct VelocityComponent "((0, 0) if not defined)"

number of tick from server

331

Legend

ID: size_t
X: int
Y: int
Velocity*: float
Enum: Color
{c++}

enum class PlayerColor {

CYAN = 0,

PURPLE,

LIME,

RED,

BLUE,

COUNT // keep last

};
Enum: Team
enum ECS::Components::TeamGroup {

ALLY,

ENEMY

};

Usage of the UDP protocol to send and receive data

Example with missiles, each data transferred has at least a header and a footer

Example to receive

 {c++}
header packet = getHeader(received);
bodyMissile missileData = getMissile(str);
BodyNumber footer = getBody(str);

Each type of body has a structure and a getters to extract that structures

Example to send

 {c++}
std::string res = "";
res.append(Send::makeHeader(321, eId));
res.append(Send::makeBodyMissile(pos, vel, team, 1));
res.append(Send::makeBodyNum(321);

Here you firstly create a Headerwith rfc code and entity, then fill a bodyMissile structure with X/Y position/velocity, teams and strength

How to use Clang-tidy Config on VScode ?

Firstly Open Vscode and go to Settings

Then go to Workspace

you should see this windows

After that type "**code analysis**" turn C_Cpp > Code Analysis > Clang Tidy : Enabled to True

And specify the path to .clang-tidy from our source file for example /home/YourName/SourceFolderWhere.clang-tidy

How to use Editor Config on VScode ?

Start by running
npm i -g editorconfig

in your terminal to make sure the extension will work.
Then, open your VScode and go to the settings (File > Preferences > Settings)
Search for format on and check Editor:Format on Save
If you use autosave, you need to also check Editor:Format on Type
Then search for the EditorConfig.EditorConfig extension and install it
